Description

6″ PXCYL DIRECT INDIRECT INDOOR CYLINDER

PXCYL Up and Down Cylinder

Sales Sheet

Quick Facts

  • SelectDrive Technology – 3 defined light levels
  • Innovative dual directional optical design
  • A complementary solution in PXCYL cylinder series
  • Central monopoint suspension for shadowless uplight
  • A shallow design and refined finish
  • Proudly assembled in the US and customizable

Discover the pinnacle of suspended cylinder lighting with a uniquely singular point fixture that delivers pristine direct and indirect illumination.

The design enhances spatial perception and eliminates any trace of a cave-like feel.

Innovative Dual Directional Optical Design

The unique circular upward optic design allows for both indirect and direct light sources to be packed within a compact cylinder profile. With only 1.5” depth added, the product elevates your atmosphere with a brighter and more spacious ceiling while still keeping a pleasant unobstructive floating cylinder in the space.

UPLIGHT

Light Output 30% (500lm – 1,600lm)
Beam Angle 60° / 75°

DOWNLIGHT

Light Output 70% (1,300lm – 4,000lm)
Beam Angle 15° / 25°/ 40°/ 60°/ 75°

2 Lumen Packages

SelectDrive Driver with Two Dimming Options

Medium Light Engines

Direct Downlight: Low 1,275lm / Medium 1,750lm / High 2,150lm
Indirect Uplight:  Low 475lm / Medium 695lm / High 850lm

Large Light Engines

Direct Downlight: Low 2,800lm / Medium 3,400lm / High 3,950lm
Indirect Uplight:  Low 1,200lm / Medium 1,450lm / High 1,650lm

Various Colors

Cylinder Finishes

Reflector Colors

Please contact factory for customized finish and reflector options

PXCYL-13

Matt White

PXCYL-14

Matt Black

PXCYL-15

Matt White

PXCYL-16

Clear

PXCYL-17

Customized

Pendant/Suspension Mountings

Two Sizes Options

Direct Downlight
5 Beam Angles

Indirect Uplight
2 Beam Angles

Central Monopoint Suspension for Clean Shadowless Light

Available for either stem pendant or cable suspension with central monopoint mounting, the PXCYL direct / indirect cylinder brings a clean shadowless upward lighting effect on the ceiling, providing a sense of depth and security while limiting the cave effect.

A Complementary Solution in PXCYL Cylinder Series Family

Featuring the same design and finish options as the PXCYL downlight cylinders, the direct/indirect model also includes SelectDrive technology, allowing for three adjustable lumen output levels. With a high CRI of 90 and precise LED binning, it provides excellent color accuracy and uniform illumination in both upward and downward directions.

Surface
Downlight
2″/ 4″/ 6″/ 8″

Wall
Uplight
2″/ 4″/ 6″/ 8″

Wall
Downlight
2″/ 4″/ 6″/ 8″

Track
Downlight
2″

Suspension
Downlight
2″/ 4″/ 6″/ 8″

Suspension
Up & Down Light
4″/ 6″

Pendant
Downlight
2″/ 4″/ 6″/ 8″

Pendant
Up & Down Light
4″/ 6″

Contact Us (866) 774-5433

Follow Us

Facebook
Twitter
YouTube
LinkedIn

Additional information

Model Number

PXCYLDI6/xx/LEL9xx/DIM010UNV/xx/xx/xx/xx, PXCYLDI6/xx/LEL9xx/DIM120V/xx/xx/xx/xx, PXCYLDI6/xx/LEM9xx/DIM010UNV/xx/xx/xx/xx, PXCYLDI6/xx/LEM9xx/DIM120V/xx/xx/xx/xx

Color

White, Black

Warranty

5 Year

CCT

3000K, 3500K, 4000K

Lumens

selectable, 1275, 1750, 1785, 2150, 2480, 2800, 3000, 3400, 3950, 4000, 4850, 5600

Beam Angle

 75°, 15°, 25°, 40°, 60°

CRI

90

Dimming

Yes, 0-10V, 120V, TRIAC/ELV

Rated Lifetime (Hours)

50,000

Voltage

120V, 120-277V

Enclosed

No

Energy Star

No

JA8

Yes

DLC

No

Environmental Location

Damp

Finish

Black, White

Dimension (Shape)

6"

Power

25.5W, 31.5W, 37.5W, 48.5W, 18W, 60W

New

Yes
